Hex Nuts with Flange

Hex Nuts with Flange

£3.32 - £29.65
£3.32
£3.32 - £29.65
£3.32
Description

Hex Nuts with Flange

  • Product class A ‚ÄìDIN 6331
  • Hardness Class 10
Thread Comments Part no Price £ Quantity
M8 A/F= 13, Thickness= 12 331-08 3.32
M10 A/F= 16, Thickness= 15 331-10 3.44
M12 A/F= 18, Thickness= 18 331-12 3.50
M14 A/F= 21, Thickness= 21 331-14 4.21
M16 A/F= 24, Thickness= 24 331-16 4.98
M18 A/F= 27, Thickness= 27 331-18 6.87
M20 A/F= 30, Thickness= 30 331-20 7.48
M22 A/F= 34, Thickness= 33 331-22 10.87
M24 A/F= 36, Thickness= 36 331-24 12.51
M30 A/F= 46, Thickness= 45 331-30 29.65
Thread
M8
331-08
£3.32
M10
331-10
£3.44
M12
331-12
£3.50
M14
331-14
£4.21
M16
331-16
£4.98
M18
331-18
£6.87
M20
331-20
£7.48
M22
331-22
£10.87
M24
331-24
£12.51
M30
331-30
£29.65
M8 331-08 3.32
M10 331-10 3.44
M12 331-12 3.50
M14 331-14 4.21
M16 331-16 4.98
M18 331-18 6.87
M20 331-20 7.48
M22 331-22 10.87
M24 331-24 12.51
M30 331-30 29.65
